Arm Morello Program
Morello was a research program with the potential to radically change the way we designed and programmed processors in the future to improve built-in security. Funded by the UK government’s Industrial Strategy Challenge Fund (ISCF) Digital Security by Design (DSbD) program and led by Arm, Morello had a transformative goal to radically update the security foundations of the digital computing infrastructure that underpinned the entire global economy. The main output of DSbD was a technology platform prototype, designed and produced by Arm: the Morello evaluation board.
Morello focused on new ways of designing CPU architecture that could make processors more robust and deter certain key security breaches. As part of an additional 5-year research program funded by UK Research and Innovation (UKRI), Morello was used to produce and test a prototype technology that, if successful, could be implemented in future hardware.
Arm collaborated with the University of Cambridge and SRI International on its Capability Hardware Enhanced RISC Instructions (CHERI) architecture. Arm developed a prototype architecture that adapted the hardware concepts of CHERI.
This new approach to cybersecurity required extensive exploration work and involved a significant change in how the architecture of the hardware was designed and how software running on devices was programmed to take advantage of the new features.
Using this new technology, Arm designed a prototype system-on-chip (SoC) and a development board, called the Morello board. This enabled industry and academic partners to test the new prototype architecture in real-world use cases.
Timescale
The Morello Program began in 2019 and spanned a 5-year period. In 2022, Arm began shipping hundreds of Morello demonstrator boards to companies, universities, and government labs for experimentation and evaluation. This then allowed the rest of the project time to be used for testing and feedback by the industry ecosystem.
Technical Resources
Access the following resources for Morello, including architecture specifications, platform models, the Morello forum, technical guides and more:
Morello Prototype Architecture Specification
The Morello architecture aims to improve the robustness and security of systems.
Work With Open Source Software for the Morello Platform
See the Linaro landing page for Morello Linux open source software.
Morello Platform Model
Download the open access Fixed Virtual Platform (FVP) on developer.
Morello Technical Reference Manual (TRM)
Find out more about the Morello System Development Platform (SDP).
Morello Development Tools
Get specialized tools for software prototyping and architecture exploration.
Memory Model Tools Support for Morello
Access support for the Morello architecture on github.
Morello Theory
- The hardware capability technology that is used in CHERI and in the Arm prototype architecture confines references to memory locations. These act as pointers, with limits on how the references can be used. These limits relate to the address ranges and functionality that the references can be used to access.
- This combined information, which is called a capability, is constructed so that it cannot be forged by software.
- Replacing pointers with capabilities in a program vastly improves memory safety, which is a key step for security. Recent research by Matt Miller of Microsoft has shown that ~70% of the vulnerabilities addressed through a security update each year continue to be memory safety issues.
- The benefit of hardware capability technology goes beyond memory safety. This is because the capabilities can be used as a building block for more fine-grained compartmentalization of software. Software that is constructed with fine-grained compartmentalization could result in inherently more robust software that is resistant to attack.
- A powerful feature of compartmentalization is that, even if one compartment is compromised by an attacker, the attacker cannot break out of the compartment to access any other information, or to take overall control of the computing system.
In addition to changes to hardware, this new approach to security will require re-architecting how code is created. Code will be written and compiled in a different way, to take advantage of the novel hardware features and to achieve a more secure result.
Prototype Morello Evaluation Board
By creating a prototype Morello evaluation board, Arm committed to the extensive engineering and research that enabled an industrial-scale trial of candidate technologies. This was the first trial of this scale in the UK.
The Morello prototype board was made available to appropriate software companies, tools developers, and leading academic institutions. Arm published its key findings widely to lead and enable industry change. The CHERI Alliance is now distributing Arm Morello boards. You can still register your interest in a board through the CHERI Alliance here.
The Morello prototype board is subject to these terms and conditions.
Note: Morello technology is at an early stage of research and testing. Arm has no roadmap or plan to include Morello technology in any current or future Arm products or architectures.
